Miniature pogo pins

Miniature pogo pin tips, recommended collection

Just like its name, the “mini pogo pin” is also a kind of pogo pin, but it is very small and the space usage rate is very low (special space saving)

First, the application of miniature pogo pins. Is a new type of connector system suitable for use in confined spaces. If the product requires a flat design or modularity of the final product, the use of mating connectors should be avoided, so miniature pogo pins are an ideal choice. The connector is pushed directly onto the contact pads on the printed circuit board.

Second, the product attributes of miniature pogo pins. The rated current can reach 10A, the minimum pin pitch is 0.4mm (through-hole) / 0.3mm (surface mount), and the service life is greater than 50,000 cycles. With high vibration resistance, it can be suitable for data transmission or current transmission of thin and light mobile phone modules (display, audio jack, charging and other modules).

Third, the miniature pogo pin structure and working principle. Like a normal pogo pin, a miniature pogo pin connector includes a thin tube with a spring and a thimble. The spring pushes the needle against the contact pads on the printed circuit board, establishing a reliable, vibration-resistant electrical contact.

Fourth, custom design. Mini pogo pins are available in custom pogo pins and in-use heights that meet specifications. The product can be applied to a fully automated production line. Choice of custom designs including different shapes of pins and connector housings, protectors, packaging or mating female headers.

fifth, Standard design. Customers can freely choose the design according to the special requirements of the project. In addition to the irregular structure, customers can also use pogo pins as the new standard for single-row, double-row or multi-row pin products.

For more information and solutions or sample applications of micro springs, please contact our online customer service. Topology-to provide you with more professional products and services.
